- Pre-assembled solution with rack, 500 W cooling and power panel.
- Indoor 24U sealed enclosure to protect IT equipment from dust and water threats. IP54 rated
- Remotely manageable cooling unit with RS485 MODBUS RTU interface
- Noise level below 65 dB
- Optimized design for IT and OT applications
Keterangan
Spesifikasi Rack MDC24UR500ACI
| Overview | |
| Presentation | Solusi Ecostruxure Micro Data Center untuk penerapan aplikasi Industrial Edge. Mudah digunakan, mudah dikelola – disesuaikan untuk penggunaan industri dan aplikasi komersial yang memerlukan perlindungan terhadap debu dan air. |
| Lead time | Usually in Stock |
| Main | |
| Range | EcoStruxure |
| Product or component type | Micro data center |
| Assembly style |
|
| Complementary | |
| Cable support type | High side |
| Network frequency | 50…60 Hz |
| Environment | |
| ambient air temperature for operation |
|
| Physical | |
| height | 1300 mm |
| Width | 800 mm |
| Depth | 1000 mm |
| Number of rack unit | 24U |
| available rack space | 24 |
| Net weight | 160 kg |
| minimum mounting depth | 190 mm |
| Maximum mounting depth | 850 mm |
| Baying included | No |
| Permanent permissible load |
|
| Conformance | |
| IP degree of protection | IP54 |
| product certifications |
|
| Packing Units | |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 175 cm |
| Package 1 Width | 130 cm |
| Package 1 Length | 117 cm |
| Package 1 Weight | 305 kg |
| Contractual warranty | |
| Warranty | 1 year |
Tipe EcoStruxure Micro Data Centers lainnya:
AR4340IX500 – MDC43UACSI – MDC43UBCSI – MDC43UECSI – MDC43USCSI – AR4340IX500CP – ARFS600 – MDC15UR500ACI- MDC24UR1KACI- MDC24UR500ACI – MDC42UR2KACI
